PRODUCT OVERVIEW Wall Connector Internal Components 1. RS-485 port 2. Contact blades 3. Temperature sensor 4. Conductor terminals 5. Zip tie anchor 6. Sliding contacts 7. Wirebox drainage opening (enables Type 3R protection) 10 Gen 3 Wall Connector Manual
